ACO DRAIN® Multiline
ACO DRAIN® Multiline is based on a system idea which provides advantages for everyone: planners, dealers, contractors and building owners. Five load classes, six nominal widths, three frame designs - an innovative concept. Planners save time during the tendering process because the Multiline system idea enables a high degree of standardisation of the interfaces. Dealers benefit from the extremely tight product range. And building owners are always very pleased about sophisticated solutions for design and construction. Multiline combines creative diversity, high functionality and extreme durability.
Contact us:
Jeslyn Teo
Tel: +6012 326 2960
Email: Jeslyn.Teo@aco.com
Click for WhatsApp
Multiline – cast iron rail unsloped
| Product Type | Load class | mm | mm | mm | kg | Art. No | |
| Length | Width | Height | Weight | ||||
| Multiline V100 | 0.0 | E600 | 1000 | 135 | 150 | 16.8 | 135630 |
| 10.0 | 1000 | 135 | 200 | 21.1 | 135650 | ||
| 20.0 | 1000 | 135 | 250 | 24.9 | 12470 | ||
| Multiline V150 | 0.0 | 1000 | 185 | 210 | 29.2 | 12930 | |
| 20.0 | 1000 | 185 | 310 | 38.4 | 12970 | ||
| Multiline V200 | 0.0 | 1000 | 235 | 265 | 39.3 | 13330C | |
| 10.0 | 1000 | 235 | 315 | 43.9 | 13350 | ||
| 20.0 | 1000 | 235 | 365 | 47.6 | 13370 | ||
| Multiline V300 | 0.0 | 1000 | 350 | 385 | 64.0 | 13730 | |
| 20.0 | 1000 | 350 | 485 | 76.5 | 13770 | ||
| Grate Type | Load class | mm | mm | mm | kg | Art. No | |
| Length | Width | Height | Weight | ||||
| Multiline V100 | Cast iron grate | B125 | 500 | 123 | - | 2.3 | 12676 |
| C250 | 500 | 123 | - | 3.4 | 12670 | ||
| D400 | 500 | 123 | - | 3.8 | 23408 | ||
| E600 | 500 | 123 | - | 4.4 | 12671 | ||
| Brickslot | D400 | 500 | 135 | 50 | - | S311491 | |
| Brickslot inspection unit | D400 | 500 | 135 | 50 | - | S421491 | |
| Multiline V150 | Cast iron grate | C250 | 500 | 173 | - | 5.3 | 13070 |
| D400 | 500 | 173 | - | 6.4 | 23224 | ||
| Brickslot | D400 | 500 | 185 | 50 | - | S331491 | |
| Brickslot inspection unit | D400 | 500 | 185 | 50 | - | S441491 | |
| Multiline V200 | Cast iron grate | C250 | 500 | 223 | - | 7.6 | 13470 |
| D400 | 500 | 223 | - | 9.8 | 23224 | ||
| Brickslot | D400 | 500 | 235 | 50 | - | S351491 | |
| Brickslot | D400 | 500 | 235 | 50 | - | S441491 | |
| Multiline V300 | Cast Iron grate | C250 | 500 | 338 | - | 16.8 | 13870 |
| D400 | 500 | 338 | - | 23.5 | 13871 | ||
| Brickslot | C250 | 500 | 350 | 50 | - | S371391 | |
| Brickslot inspection unit | C250 | 500 | 350 | 50 | - | S481391 | |
